Name: Electric Powered Pallet Truck Safty Valve Inductive Microswitch AC Drive
Brand: YONGJIELI
Price: 4 USD

Brand Name : YONGJIELI

Model Number : CBD120

Certification : CE

Place of Origin : Anhui, China

MOQ : 1 SET

Price : $4,620.00~$4,950.00 PER SET

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 100 SETS PER MONTH

Delivery Time : 10 WORK DAYS

Packaging Details : EXPORT PACKING

Drive Motor : AC

Power Supply : Battery

Tyre Material : Polyurethane

Steering Type : Electronic Steering

Brake System : Electromagnetic

Brake Mode : Lever Operation

Contact Now

Electric Pallet Truck Standing American CURTIS Cylinder Safty Valve Inductive Microswitch AC Drive Portable

Model No.	CDD25
Power Supply	Battery
Driving Mode	Stand-on
Load	2500kg
Load Center Distance	500mm
Tyre Material	Polyurethane
Tyre Amount	4/1x+2
Mast type	Double
Standard Lift Height	3000 mm
Free Lift Height	/
Lowered Mast Height	2000 mm
Loading MAX. Height	3490 mm
MIN. Grounding clearance	85 mm
Overall Length	2515 mm /2115 mm
Axis	1390 mm
Overall Width	1230 mm
Track Front/Rear	505 mm/1100 mm
Fork Size	1150 mm/200 mm/65 mm
Distance of Unilateral External Fork	685 mm/560mm
Turning Radius	2125mm/1715mm
Driving Velocity (full/idle)	4.0/5.0 Km/h
Lifting Velocity (full/idle)	80/125 mm/s
Descending Velocity (full/idle)	160/105 mm/s
Climbing Velocity (full/idle)	5%/8%
Drive Motor	AC
Drive Motor Power	1.5 kw
Lifting Motor	DC
Lifting Motor Power	3 kw
Battery	24 V/210 AH
Battery Weight	200 kg
Weight (including battery)	1300 kg
Steering Type	Electronic Steering
Brake System	Electromagnetic
Brake Mode	Lever Operation
